Total weight of the NanoHawk whoop is only 19 grams 20grams. Pretty good Average weight for a 65mm whoop.
EMAX NanoHawk has new AIO F4 flight controller with integrated FrSky SPI receiver and 25mW VTX . The board mounting hole size is standard 25.4×25.4mm.
| F4 Flight Controller | FC Firmware: MATEKF411RX firmware MPU: MPU6000 |
| Onboard 5A 4in1 ESC | Con. Current: 5A Firmware: BLHeli_S |
| Onboard 5.8G 25mW VTX | 5.8G 37CH 25mW VTX |
| Onboard SPI Receiver | Compatible with Frsky D8/D16 Mode |
Available @
Makerfire (code “Nanohawk5” for 5% off) : https://shop.makerfire.com/collections/new-arrival/products/emax-nanohawk-bnf-65mm-1s-brushless-whoop
Banggood (10% coupon BGNH10): https://www.banggood.com/19g-Emax-Nanohawk-65mm-1S-F4-AIO-5A-ESC-VTX-Receiver-…-1783212.html
Specifications:
Diagonal wheelbase: (without paddles) 65mm
Maximum size of the aircraft (without antenna, cable tie) : 87×87×30(mm)
Aircraft weight (without battery): 19g 20g
Motor: TH0802II 19000KV
Propeller: Avan Nano Hawk 1201-4 propeller
Main Flight Controller: F4（MATEKF411RX firmware） 4 in one 5A ESC SPI RX receiver（Compatible with Frsky remote control D8/D16 mode）
Camera: RunCam Nano 3 Camera
VTX: 25mW Adjustable frequency 37CH.
Support SmartAudio.
Ham radio license required for use in North America.
Battery: 1S 300mAh HV lipo battery
NanoHawk user manual: http://myosuploads3.banggood.com/NanohawkBNFInstructionManualv1.2.pdf
Package included:
NanoHawk × 1
Instruction manua card × 1
Emax 1s HV 300 mAh × 1
Charger × 1
Extra Propeller Set (2x CW, 2x CCW)
Screwdriver x 1
Spare screws x 1
RC damper x 1
Rubber bands x 1
From EMAX website:
In an effort to push the boundaries of miniaturizing the FPV experience, EMAX took to the drawing board to design the smallest quadcopter possible in their history. Introducing the Nanohawk, a nano sized FPV drone designed to offer an immersive flight experience in a new scale. Weighing in at just 20 grams, the Nanohawk offers unmatched control and flight recovery, giving the pilot full control of the aircraft for any maneuver. Designed from the ground up is a modern frame design optimized for a unique mix of polycarbonate in order to offer maximum durability. Debuting with the Nanohawk is the new Avia Series of propellers, redefining aerial performance with new design goals. With the Avia Nanohawk propeller, maximum thrust is achieved while maintaining an optimized throttle curve throughout the motor’s performance, giving pilots better control than previously achieved with unique flight characteristics unparalleled with propellers in its class. The Nanohawk offers an all new nano scaled experience to FPV drones, pushing the boundaries further of what is possible.
]]>EMAX TinyHawk II Race
Emax released new TinyHawk. This time with 1103 7500KV motors facing up, carbon fiber frame and Avan 2″ props.
https://emax-usa.com/emax-tinyhawk-2-race-fpv-drone-bnf.html
HGLRC Forward 60A 4in1 ESC
60A 4in1 ESC with CNC heat sink for better thermal conductivity.
Available @ HGLRC: https://www.hglrc.com/products/hglrc-forward-60a-3-6s-blheli-32-4in1-esc-for-fpv-racing-drone
Flysky FTr4 receiver
AFHDS3 protocol, 4 Channel, iBUS output, range: > 3500m (air)
iFlight Nazgul Cine prop
iFlight posted a picture with a new Nazgul Cine propeller for cinewhoops. Looks like the size is 3 inch.
HQProp T3X1.5
QHProp have posted a teaser photo of the two new props with T-mount T3X1.5 and T3X1.5X3.
Source: Facebook, Instagram, etc.
]]>ECO Micro 1106 motors have single-stranded winding while 1404 and 1407 motors have multi-stranded windings. All motors have simpler non-curved magnets as in all ECO series motors.
Info on EMAX website: https://emax-usa.com/catalogsearch/result/?q=ECO+Micro+series
ECO Micro Series 1106
Available in 4500KV and 6000KV
Specifications
- Framework: 9N12P
- Length: 19.9mm
- Diameter: 14.2mm
- Propeller: 2″ – 3″
- Weight: 6.7g (W/O Silicone Wire)
- Prop adapter shaft diameter: 1.5mm
- Bearing Shaft: 2mm
- Shaft Thread: CW
Features
- Precision durable ball-bearings
- Steel shaft for high strength
- Anodizing for finish and corrosion resistance
- 9x9mm hole pattern
- Single-strand copper windings
- 100mm 26 AWG silicone wire
ECO Micro Series 1404
Available in 3700KV and 6000KV.
Specifications
- Framework: 9N12P
- Length: 19.75mm
- Diameter: 18.8mm
- Propeller: 2.5″ – 4″
- Weight: 8.6g (W/O Silicone Wire)
- Prop adapter shaft diameter: 1.5mm
- Bearing Shaft: 2mm
- Shaft Thread: CW
Features
- Precision durable ball-bearings
- Steel shaft for high strength
- Anodizing for finish and corrosion resistance
- 9x9mm hole pattern
- Multi-strand copper windings
- 100mm 26 AWG silicone wire
ECO Micro Series 1407
Available in 2800KV, 3300KV and 4100KV options.
Specifications
- Framework: 9N12P
- Length: 31.2mm
- Diameter: 18.8mm
- Propeller: 3″ – 4″
- Weight: 13.7g (W/O Silicone Wire)
- Prop adapter: M5
- Bearing Shaft: 2mm
- Shaft Thread: CW
Features
- Precision durable ball-bearings
- Steel shaft for high strength
- Anodizing for finish and corrosion resistance
- 12x12mm hole pattern
- Multi-strand copper windings
- 90mm 26 AWG silicone wire
EMAX ECO series motors comes in 2306 size and in two KV options: 1700KV for 6S battery setups and 2400KV for 4S battery setups. Motors features large 9x4mm size ball bearings, hardened stainless steel hollow shaft, lightweight bell and open base motor design.
Available @:
Emax website https://www.emaxmodel.com/ec0.html
Specification:
Brand name: Emax
Item name: ECO series 2306 brushless motor
KV: 1700KV, 2400KV (option)
Framework: 12N14P
Length: 30.2mm
Diameter: 27.7mm
No. of cells: 3-4s 2300-2700kv range
No. of cells: 3-6s 1500-1900kv range
Propeller: 5″ – 6″
Light Weight: 28.3g (W/O Silicone Wire)
Prop adapter: M5
Bearing Shaft: 4mm
Shaft Thread: CW
Features:
-EZO bearing 9mm ODx4mm ID
-Steel shaft
-Dual anodizing
-16x16mm hole pattern
-Multi copper winding
-115mm 20 AWG silicone wire
Package included:
1x ECO series 2306 brushless motor
The whoop style unibody frame is made of polypropylene, inside the quad there is F4 processor based flight controller , with a 4in1 3A ESC. It drives 15000KV brushless 8×2.5mm (08025) sized motors and Emax three-bladed 40mm size propellers. Propellers are designed specially for this quad and are incompatible with the other quads, they are press fitted on the motor bell.
The FPV camera is CMOS 600TVL with a 5.8 GHz 37 channels, 25mW transmitter.
The receiver is Emax Tiny Receiver, compatible with the FrSky D8 mode. To power everything, you need a battery LiHV 1S 3,8V 450 mAh.
Weight of the Tiny Hawk is 28 g without the battery and about 41 g with 1S 450mAh battery.
More info should be released in AMA Show on 2018-11-02
Update 2018-11-02: Emax TinyHawk was oficially released at AМА Show. Estimated price is $159 for the kit or $99.99 for quad only.
As you see in the picture, there will be also a kit available, including TinyHawk, Transmitter and Goggles.
Available:
@ EMAX https://emax-usa.com/tinyhawk2.html
@ Banggood https://www.banggood.com/Emax-Tinyhawk-Indoor-FPV-Racing-Drone-BNF-…-1375328.html
@ Heli Nation https://www.heli-nation.com/emax-tiny-hawk
& all major webshops
Features:
75mm Indoor racing drone
08025 brushless motor with durable ball bearing for increase flight and low maintenance
Durable polypropylene plastic frame with propeller guards
Motor beeper function. Find your tinyhawk after a crash
Speeds up to 56kph
Up to 4 minutes flight time on single battery
Fast F4 Processor for smooth stable flight characteristics
MPU6000 gyro for vibration free operations
Unique inverted motor design to keep CG as low as possible to fit in the smallest of spaces
25mw VTX and 600tvl Camera included for fun FPV flight via FPV style goggles
Smart Audio function to change VTX channel via your transmitter
OSD settings control to customize flight feel
Pre-tuned from factory with expert pilots and new pilots in mind. 3 rate profile settings for all types of flying feel
Plug in type motors for easy maintenance
1s High Voltage (HV) 450mah lipo included
Frsky compatible D8 receiver built in to FC
Custom carbon fiber themed carrying case
Motor Properties:
Stator: 8mm x 2.5mm (08025)
Kv: 15000kv
Weight: 2.5g
Bearing Size: Φ1.5*Φ4*2mm
Shaft Diameter: Φ1.5mm
Propeller Mount: Press Fit Over Bell
Main PCB:
Flight Controller: F4（MATEKF411 firmware）
ESCs: 4in1 3A
Receiver: EMAX Tiny receiver (Compatible with Frsky D8 mode)
Battery Connector: JST-PH2
Camera and VTX:
VTX Power: 25mw
Channels: 37CH
Camera Properties: 600TVL CMOS
Smart Audio
Battery:
Voltage: 1s 4.35v HV
Capacity: 450 mAh
Discharge rating: 80c/160c
RS1606 3300KV 4000KV
3-4 inch quadcopters always struggle as the old motor choices were limited to 14xx series motors or bigger 18xx series motors. EMAX brings the 1606 sized powerful motor in a small package to get the correct AUW for 3-4 inch quadcopters. This is also great for frames that are using more HD style components like the RunCam split to carry the extra payload.
RS1606 motors are available in 3300KV and 4000KV ratings. Weights only 15.8 grams and provide more than 1kg of thrust on 4S!
Available @
https://www.emaxmodel.com/rs1606-brushless-racing-motor.html
Framework: 9N12P
Length: 28.1
Diameter: 20.8mm
No. of Cells: 3-4S
Max. Thrust: 4000-1027g (on 4s) 3300kv-875 g (on 4s)
Prop shaft thread type: M5
Propeller: 3″ – 4”
Weight: 15.8g (W/O silicone wire)
Wire Length: 85mm 24AWG
Motor mount bolt pattern: 12mmx12mm M2 Thread
RS1306 V2 2700KV 4000KV
EMAX also introduced new line of RS1306 motor. We can call it RS1306 Version 2 . Motor was redesigned from the ground up to have better performance. The older motor pulled about 315g of thrust on 4S battery and the new one pulls up to 500g of thrust on 4S! The bottomless design and T-mount system allowed to make the smaller and lighter motor. The weight of the new RS1306 motor is only 9.6g versus the 12.7g of the older one.
Availagle @:
https://www.emaxmodel.com/rs1306-version-2-brushless-racing-motor.html
Framework: 9N12P
Length: 19.4mm
Diameter: 16.8mm
No. of cells: 3-4s
Max thrust: 4000kv–500g(on 4s) , 2700kv–336g(on 4s)
Shaft diameter 1.5mm
Propeller: 3″
Weight: 9.6g (W/O silicone wire)
Wire Length: 65mm 26AWG
Mounting : T-Mount (M2 holes, 5mm eye to eye)
Motor mount bolt pattern 12mmx12mm M2 Thread
Bearing: 2x5x2.5
]]>The main upgrades are: Babyhawk R PRO now comes with unibody 120mm frame, that fits the AVAN Rush 2.5 inch props, new version of F4 Mini Magnum 2 lite flight controller, 25amp 4in1 BLHeli_32 ESC.
Babyhawk R PRO has changed the camera from Foxeer Micro Arrow CCD to EMAX edition Caddx S1 CCD camera.
Other goodies: 2 programmable RGB leds, 5 UARTS (although questionable statement!), On-board current sensor, Smart audio controlled VTX with MMCX antenna connector. EMAX states, that Magnum Mini 2 FC has 5 UARTS, however it is only partially true. F4 MCU is really capable to provide 5 UARTS, but there is no extra UART Tx/RX pads available on the board. The available ones are already used – one for SBUS/PPM other for SmartAudio and there is no free TX/RX pads for Telemetry or Frsky F-port or connecting the CrossFire! So have this in your mind!
We all are curious how much does it weight, but no available information about weight yet. Babyhawk R Pro weights 91.5 grams without battery. So it is even heavier than 3″ inch Babyhawk R (86.5 grams)
Be warned that this Babyhawk R Pro version has the same RS1106 6000KV motors as in previous Babyhawk R version, so 4S batteries could be too much for Avan Rush 2.5 propellers. That’s why it is rated 2S-3S only.
Listed @
Technical Specifications:
-
- Model: EMAX Babyhawk R Pro 2.5 BNF
- 120mm unibody frame with PC durable canopy/pod
- Mini Magnum F4 2 lite
- 25amp 4in1 BLHeli_32 ESC 20×20 mounting
- On board ESC Current Sensor
- F405 Matek HEX Target using Betaflight OSD
- 5 available Uart ports
- 2 onboard RGB programmable LED’s
- 1106 6000kv Brushless Motors
- EMAX Rush 2.5 inch propeller
- 25-200mw FCC compliant VTX with Raceband Channels
- Smart Audio control feature
- MMCX Connector
- D8 channel receiver
- EMAX/Caddx S1 CCD FPV Camera
- AUW without battery 91.5 grams
- Camera Tilt Angle: 20-70 degrees
- Recommended Batttery for optimal flight 450-650mah 3s lipo min 50C burst rated
Updated: 2018-09-06
Magnum Mini 2 has 20x20mm mounting pattern, but the lowest plate ins tack (4in1 ESC) size is 37x32mm, because it has larger MOSFETs and two LowESR caps on board.
Previous version of Magnum Mini had F3 processor and only 12A ЕSC in stack.
Citation from Emax announcement: “Engineered around an F4 processor with an MPU6000 gyro, tuning and perfect flight performance will be easier to achieve than ever. Including built-in programmable RGB LEDs, distinction between different builds and custom status updates offer a wide variety of customizability for any situation and requirement.
Utilizing a newly engineered video transmission frequency controller, channel selection can now be programmed from an external transmitter without the need to physically access the video transmitter. With On-Screen-Display, information regarding your craft will be easy to access while in flight directly on your video feed.
With all the electronics needed, assembled together in an accessible package, building a custom craft will only require a frame, camera, set of motors, and a compatible receiver.
Installation has never been easier, thanks to the universal form factor of the tower system”
Available @
Banggood: https://www.banggood.com/EMAX-Mini-Magnum-2-F4-…-1316934.html
User Manual: https://drive.google.com/file/d/1WrHFXpbMGCUid6cFjpGZrQJQBhHBxpz1/view
Features
Flight controller
(OMNIBUSF4 Firmware)
o STM32F405 MCU
o MPU6000 accelerometer/gyro (connected via SPI)
o On-board OSD
o On-board Buzzer
0 Integrated 5V/3A BEC
o Dedicated PPM/ SBUS receiver input
o 2omm mounting holes.
ESC
o Continuous current 35A ( max burst 4oA)
o Supply voltage 2S-6S (1700KVMotor LIMIT for 6S)
o STM32Fo51K6U6 ESC MCU
BLHeli_32 firmwares supporting. DSHOT MULTISHOT ONESHOT125
o Top quality MOSFET
o 3OZ high TG PCB board
o 32x37mm board with 2omm mounting holes.
VTX
o Frequency band: 5658-5945MHz FCC Compliant Channels / with HAM unlock)
o TBS Audio Control (Smart Audio)
o Channels: 37
o Transmit power: 13dBm/23dBm (25mW/20omW)
o Supply voltage: 4.5V-5.5V
o Antenna port : u.FL
0 Total weight: 17.21g
]]>RSII-2206 motors will be available in 1700KV, 1900KV, 2300KV and 2700KV for 4S-6S battery setups.
RSII-2306 motors will be available in 1600KV, 1700KV and 2400KV options for 4S-6S setups.
Weight of the RSII-2306 motor is only 26 grams (without wires). EMAX promises outstanding performance and efficiency of these motors.
Available @
EMAX USA:
https://emax-usa.com/rsii-2206-race-spec-brushless-motor-4-6s/
https://emax-usa.com/rsii-2306-race-spec-brushless-motor-4-6s/
https://emax-usa.com/rsii-2306-race-spec-brushless-motor-4-6s/
https://www.banggood.com/EMAX-RSII-2306-1600KV-1700KV-1900KV-2400KV-2600KV-…-1307136.html
]]>Some highlights:
FRAME
-Light weight carbon fiber frame with impact resistant plastic canopy available in several colors
-Strong 3mm arms with lower profile arms to reduce drag.
-Integrated flight controller vibration dampening system for a smoother and more locked in feeling flights
POWER SYSTEM
-Powered by the new Magnum Mini tower system with F3 FC + 4 in 1 12A BLHELI S ESC 3-4s
-Betaflight Firmware 3.2.X with comes pre tuned at the factory for optimized flight performance
-Class leading Emax RS1106 6000kv brushless motors paired with the new Avan 2” quad blade propeller for maximum speed and control.
FPV SYSTEM
-650TVL Micro CCD camera with tuned profiles for different light condition. CCD is preferred by more pilots over CMOS for its better handling of high contrast lighting and resistance to “jello” in your flight video.
– Canopy has adjustable camera positions so pilot can tune for track speed and size.
– 40 Channel 5.8g VTX with LED info display and switchable transmission power from 25/200mw
Video [https://www.youtube.com/watch?v=5_g7Z8-VXY8]:
Listed @ Banggood: https://www.banggood.com/Emax-Babyhawk-R-RACER-Edition-112mm-…-1237259.html
@ Gearbest: https://www.gearbest.com/brushless-fpv-racer/pp_1413703.html (You can try the coupon code “RC18OFF” for additional discount)
@ Emax: http://emax-usa.com/emax-babyhawk-race-r-edition-fpv-quadcopter-pnp/
User manual: https://www.emaxmodel.com/download/Babyhawk_R_Manual.pdf
Features:
-High Speed power system featuring RS1106 motors and the Avan Micro propellers
-FC/ESC AIO – Mini Magnum Tower
–112mm Carbon Fiber Frame
-Weight 82.5 grams
-Customizable Shell Canopy with adjustable camera positions
-Pre-tuned Betaflight Firmware for optimized flight performance
–OSD integrated with Low-Voltage detection
–40 Channel 5.8g VTX switchable 25/200mw
-Compatible with EMAX Transmitter/Goggles/Accessories (What? Emax Transmitter? Goggles? )
-Micro CCD Camera
-Accepts 3-4 cell LiPo batteries
